They seem to be a number of misconceptions on what reducing dimensions of size buys you. With each reduction, there is always some trade off where one of the physical laws of physics becomes the dominant limiter. Before 120 nm it was the capacitance of the transistors to the die. From there to about 40 nm it was the low gain of the P-channel transistors. From the P-channel were fixed by the fin-fets. At around 10 to 7 nm the problem is becoming the internal resistance of the interconnecting wires and even fin-fet has lost its shine. 14-10 nm is about the limit of practical I/O drive. Real world interconnect wires are about 100 ohms impedance. Even with voltage reduction, noise limits it are becoming more difficult to deal with I/O.
It seems that around 5GHz is about the lower limit of practical silicon use. Going below 10 nm doesn't help that. The thought of even a 10 gHz 6502 at 14 nm doesn't make sense. Remember, the Intel processors are not doing everything in a single cycle like the 6502 is. These processors that are doing this level are there because they use pipelining and speculative execution ( causing side band security leaks ). Having the processor fetch, decode, execute and store data like the 6502 does within one or two clock cycles at even 5 gHz doesn't even sound practical. There are too many limiting cases.
Dwight
